Catalogue number : 5200505-02
We provide a primary containment working area containing an airflow system: 70% air recirculation, 30% air exhaust, for the research and other cell culturing applications.
We provide a primary containment working area containing an airflow system: 70% air recirculation, 30% air exhaust, for the research and other cell culturing applications.
Accommodates centrifugal fan, speed, adjustable, motorized front window. We provide a safe and secure laboratory workspace using an optimum airflow design combined with an integrated H14 HEPA filter. This H14 traps the toxic particle coming from outside.
Our A2 Cabinet is suitable for working with microbiological research in the absence of volatile or toxic chemicals and radionuclide. Built-in 3 protection shields including operator, sample, and environment.
Accessories
LCD Display
Work Zone
UV lamp
Waterproof Sockets
Standard Accessories |
Optional Accessories |
Fluorescent lamp |
Base stand |
UV lamp - 2 |
Universal caster with brake and levelling feet |
Remote control |
|
Waterproof sockets - 2 |
|
Model |
IBC-100A2 |
Front Window |
Motorized 2 layer laminated toughened glass ≥ 5mm. Anti UV. |
Alarm (audio & Visual) |
Filter replacement, window over height, abnormal air flow velocity. |
Maximum Opening |
370 mm |
In Flow Velocity |
0.53±0.025 m/s |
Down flow Velocity |
0.33±0.025 m/s |
Control System |
Microprocessor |
Sockets |
2 sockets: 500 W |
Display |
LCD display |
Illumination |
≥1000 Lux |
HEPA Filter |
Two, 99.999% efficient at 0.3μm. Filter life indicator |
UV lamp |
15W*1 |
Fluorescent Lamp |
40W*1 |
Noise |
EN12469 ≤ 58 dB / NSF49 ≤ 61 Db |
Power Consumption |
500 W |
Internal Dimension |
600x500x540 mm |
External Dimension |
700x650x1230 mm |
Packing with base stand Dimension |
860x960x1450 mm |
Packing without base stand Dimension |
860x800x1450 mm |
Gross Weight with base stand |
196 kg |
Gross Weight without base stand |
164 kg |
Electrical Requirement |
220V/50Hz |
Catalogue No. |
5200505-02 |
