Catalogue number : 440210-05-04
Parallel Light Zoom Stereo Microscope IMS-3200 is the advanced Tilting type of microscope.
Parallel Light Zoom Stereo Microscope IMS-3200 is the advanced Tilting type of microscope. The Tilting trinocular viewing head with point high field eyepieces and has excellent zoom objective to choose 0.8X-10X and Plan Apochromatic: 1X78 mm, with optional choice 2X20 mm objectives, and each eye tube has interpupillary adjustment. IMS-3200 Series is capable of providing strong images with a broad field of view, the multipurpose and perfect for basic studies of samples properties. Come with LED lights, allowing samples to be illuminated for a more comprehensive field of view. Suitable for Industrial, Medical and Scientific Research Areas, circuit board repair, circuit board inspection, surface mount technology work, electronics inspection, coin collecting, gemology and gemstone setting, engraving, and repair and inspection of small parts. Provide upright, un-reversed 3 D images. Used to examine the huge specimen under 0.8X-10X low zoom magnification objective and 1:12.5 zoom ratios.
Sample Images

Accessories

Tilting viewing head for comfortable operation

Large zoom ratio 12.5:1

Apochromatic objective

Aperture diaphragm
| Model | IMS-3200 |
| Type | Parallel Light Zoom Stereo Microscope |
| Viewing Head | Tilting trinocular viewing head, 5-45 degree adjustable; binocular: trinocular |
| Optical System | Infinite |
| Focusing | Coarse and fine coaxial focus system, integrated body with focus holder, coarse range: 50mm, fine precision 0.002mm |
| Eyepiece | plan eyepiece PL10×/23mm |
| Objective | Plan Apochromatic: 1X78mm (Optional: 2X20mm) |
| Light Source | 5W LED light box of length 270×100×130mm with single fiber |
| Optional Accessories | LED Ring light and Camera Adapter |
| Shipping Dimensions | 590x550x810 mm |
| Shipping Weight | GW-16 kg NW-14 kg |
| Magnification | 0.8X-10X |
| Zoom Ratio | 01:12.5 |
| Catalogue No. | 440210-05-04 |
|
Model |
IMS-3200 |
|
Type |
Parallel Light Zoom Stereo Microscope |
|
Viewing Head |
Tilting trinocular viewing head, 5-45 degree adjustable; binocular: trinocular= 100:0 or 0:100; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
|
Magnification |
0.8X-10X |
|
Optical System |
Infinite |
|
Zoom Ratio |
01:12.5 |
|
Focusing |
Coarse and fine coaxial focus system, integrated body with focus holder, coarse range: 50mm, fine precision 0.002mm |
|
Eyepiece |
plan eyepiece PL10×/23mm, (optional: PL15×/16mm, PL20×/12.5mm, diopter adjustable) |
|
Objective |
Plan Apochromatic: 1X78mm (Optional: 2X20mm) |
|
Stage |
|
|
Light Source |
5W LED light box of length 270×100×130mm with single fiber (500mm), color temperature 5000-5500K |
|
Certification |
|
|
Optional Accessories |
LED Ring light and Camera Adapter |
|
Packing Dimension |
590x550x810 mm |
|
Packing Weight |
GW-16 kg NW-14 kg |
|
Electrical Requirement |
|
|
Catalogue No. |
440210-05-04 |
